1000 liter Per Hour RO Plant -Commercial-Mineral Water Plant-Mineralized Reverse Osmosis

1000 LPH Commercial RO Plant – Mineral Water & Mineralized Reverse Osmosis System

Meet the demands of large-scale water purification with our 1000 Liter Per Hour (LPH) Commercial RO Plant, designed for mineral water production, offices, factories, schools, and other commercial facilities. This system combines advanced filtration technology with high-quality components for consistent, safe, and great-tasting water.

Key Features:

• High Capacity: Produces up to 1000 liters per hour of purified water.

• Mineral Water Production: Optional mineralization ensures healthy, balanced water for drinking and commercial use.

• Durable & Reliable Components: Made with high-quality SS304/SS316, FRP vessels, and internationally recognized membranes.

Technical Specifications & Filtration Stages:

1. Pre-Treatment – Raw Water Pump:

   • Capacity: 2 m³/h, discharge pressure 4.0 bar

   • Material: SS304/SS316

   • Ensures consistent water supply to filtration system

2. Sand Filter:

   • FRP vessel (10×54) with top-mounted multiport valve

   • Removes silt, dust, rust, and invisible suspended particles

   • Media: Gravel & Silica Sand

3. Carbon Filter:

   • FRP vessel (10×54) with multiport valve

   • Removes bad taste, odor, chlorine, and inorganic chemicals

   • Media: Activated Carbon

4. 5-μ Jumbo Housing (Pre-Filtration):

   • 2 x 20” PPF cartridge housings

   • Filters invisible suspended particles before RO stage

5. High Pressure RO Feed Pump:

   • Material: SS316, vertical centrifugal

   • Capacity: 0.2–0.4 m³/h, discharge pressure 4–6 bar

   • Ensures proper pressure for membrane recovery

6. Reverse Osmosis Membranes:

   • Top-quality Filmtec / Vontron TFC membranes (USA/Vietnam)

   • Spiral-wound design, permeate TDS <30 ppm

   • Ensures removal of dissolved salts, heavy metals, and contaminants

7. Membrane Housing:

   • Heavy-duty FRP vessel (40×40), ASME certified

   • Pressure rating: 200 psi

8. Monitoring & Control:

   • Stainless steel liquid-filled pressure gauges (SS316)

   • Online flow meters for permeate and concentrate

   • Anti-scaler dosing pump (5 LPH, auto-controlled)

Ideal For:

• Commercial water supply: offices, schools, colleges, factories, hotels

• Mineral water production plants

• Large-scale water filtration for communities or public areas

Why Choose This RO Plant:

• High-volume, 1000 LPH output for commercial use

• Multi-stage filtration for safe, clean, and healthy water

• Durable construction with high-quality SS & FRP components

• Easy monitoring with gauges, flow meters, and auto anti-scaler dosing

Provide safe, purified, and mineral-rich water consistently with this 1000 LPH Commercial RO Plant – engineered for reliability, efficiency, and high performance.
